Daisy Data Displays is a leading manufacturer of industrial computing technology for a wide variety of industries. As part of our offerings, we offer various industrial monitors designed to withstand a range of working environments while enhancing productivity, reliability, and overall work safety.
Main Benefits/Features
Unlike other types of monitors, industrial monitors normally feature designs that withstand high and low temperatures in harsher environments. Specifically, they’re typically able to operate in temperatures of -30° C to 85° C. Their components can also resist extreme shock, vibration, and high humidity levels.
The industrial monitors available from Daisy Data Displays include a variety of features that make them compatible with many applications. Some of these features include:
- Military-specific customization that meets MIL-STD 901D and other specifications
- Division 1 and 2 hazardous area certifications that meet standards such as CE, FM, ATEX, and UL
- Screens made with impact-resistant polycarbonate that holds up in many environments
- Special displays and casings that hold up to exposure to elements such as salt water, rain, and sleet
- Specialized compatibility supports and options, including compatibility with night-vision goggles used in flight simulators
- Low-power designs that help reduce expenses for equipment in applications requiring reliable performance without the need for constant visuals
- All Daisy Data Displays monitors are upgradeable and serviceable
- Materials
Industrial monitors may consist of various materials to optimize performance in industrial applications. Then enclosure/housing is typically made of materials such as:
- Stainless steel
- Aluminum
- Carbon fiber or composites
- Plastics
Industrial monitor displays are often constructed with:
- Glass
- Lexan
- Polycarbonate
Choosing the Right Touchscreen Monitor for Your Application
When looking for the right industrial touchscreen monitor design for your application, there are several factors to consider:
Size and Format
Consider the specific width-to-height ratio you need for your monitor in inches. At Daisy Data Displays, our industrial monitors are available in widths ranging from 10.4 inches up to 42 inches.
Resolution
You also need to think about the resolution or overall picture quality you want with your monitor. The resolution increases with the number of pixels in a monitor, leading to a higher-quality image. The different aspect ratios are important to consider, especially when retrofitting older equipment.
Brightness
Another influencing factor to consider is the brightness of your monitor, which will depend on the environment. If you’re going to install the monitor in an outdoor setting, you’ll need more luminosity to illuminate the screen in full daylight. Our industrial displays are available with up to 1,500 nits standard brightness to ensure optimal visibility.
Mounting and Integration
You’ll need to consider mounting and integration options when choosing your industrial monitor. The VESA Mounting Interface Standard outlines the standards for mounting monitors, including the screws used, the hole dimensions, and the hole configuration on the back of the screen. Our monitors are available in VESA mount, rack mount, panel mount, pedestal mounts, and flush mount varieties.
Resistive vs. Capacitive Industrial Touchscreen Display
Industrial displays operate using two main types of technology: resistive and capacitive touchscreens. Resistive touchscreens consist of an insulation layer between two conductive layers. The conductive layers make contact when users interact with the touchscreen, allowing for the flow of electrical current. This type of screen offers high levels of accuracy and can be used with a bare finger, gloved hand, stylus, etc.
Capacitive touchscreens consist of a layer of glass coated with a transparent conductor. The user’s electrical charge travels into the screen when the user makes contact with the touchscreen. These touchscreens offer more precision but require users to interact with the screen using their bare hands.
Industries Served
At Daisy Data Displays, we serve the following industries with quality industrial computer monitors:
- Automotive
- Chemicals + Paint
- Military
- Power
- Aerospace
- Pharmaceutical
- Mining
- Manufacturing
- Food and beverage
- Transportation
- Oil and gas
- Specializations
To enhance our industrial touchscreen designs, we offer a few key specializations for various applications, including:
- Readable while wearing Night Vision Goggles
- EMI protection
- Sunlight readability
- Brightness control for military ships in applications requiring stealth
Touchscreen Cleaning and Disinfecting
Cleaning and disinfecting your industrial monitor is critical for keeping it in good shape. Here are some steps for maintaining these devices:
- Switch off the power to the device if possible.
- Use a wet cloth or wet wipes to clean or disinfect the monitor, taking care to prevent liquid from getting into the device.
- Use non-abrasive cloths that won’t scratch the touchscreen, and avoid pure alcohol and other solutions that can cause discoloration.
- Gently wipe the screen in a circular motion and give it time to air dry.
Why Daisy Data Displays?
If you require a reliable industrial touchscreen, Daisy Data Displays manufactures top-quality devices that can hold up in harsh conditions for many years. To further ensure our customers’ satisfaction, we offer a one-year warranty on our products along with a team of professionals who can efficiently repair devices as needed.
Contact us today for more information about our industrial monitors.
